Configuring the Oracle Network Environment
配置oracle网络环境
　　you should be able to:
　　Use Enterprise Manager to:
　　1、Create additional listeners
　　2、Create Oracle Net Service aliases
　　3、Configure connect-time failover
　　4、Control the Oracle Net Listener
　　5、Use tnsping to test Oracle Net connectivity
　　6、Identify when to use shared servers and when to use dedicated servers
　　Oracle Net  configuration files ：
　　/network/admin/listener.ora
　　./sqlnet.ora
　　grid用户下：
　　more  listener.ora
　　more  sqlnet.ora
　　ss  -ln
　　windows cmd>  tnsping   192.168.133.120:1521/tech1

　　Tools for Configuring and Managing the Oracle Network：
　　1、Enterprise Manager Net Services Administration page
　　2、Oracle Net Manager
　　3、Oracle Net Configuration Assistant
　　4、Command line
　　例：
　　$ . oraenv
　　ORACLE_SID = [orcl] ? +ASM
　　$ lsnrctl
　　LSNRCTL for Linux: Version 11.2.0.1.0 - Production on 30-JUN-2009 00:47:01
　　Copyright (c) 1991, 2009, Oracle.  All rights reserved.
　　Welcome to LSNRCTL, type "help" for information.
　　LSNRCTL> help
　　The following operations are available
　　An asterisk () denotes a modifier or extended command:
　　start               stop                status

　　services            version            >　　save_config         trace               spawn
　　change_password     quit                exit
　　set                show*
　　$ lsnrctl
　　$ lsnrctl start
　　$ lsnrctl status
　　LSNRCTL>
　　LSNRCTL> start
　　LSNRCTL> status
　　LSNRCTL> show  parameter  service
　　LSNRCTL> change_password  设置监听密码
　　vim   listener.ora
　　LSNRCTL>reload  重启才生效
　　Using SRVCTL to Start and Stop the Listener  使用 srvctl 起停监听
　　$ srvctl -h
　　$ srvctl start listener
　　$ srvctl stop listener
　　$ srvctl start listener –l mylistener
　　$ srvctl status listener
　　$srvctl  status  listener
　　$crs_stat  -t
　　Naming Methods 服务命名方式
　　Oracle Net supports several methods of resolving connection information:
　　1、Easy connect naming: Uses a TCP/IP connect string
　　2、Local naming: Uses a local configuration file
　　3、Directory naming: Uses a centralized LDAP-compliant directory server
　　4、External naming: Uses a supported non-Oracle naming service
　　1、 easy connect  简易连接
　　SQL> CONNECT hr/hr@db.us.oracle.com:1521/dba11g
　　2、Local naming
　　Requires a client-side Names Resolution file
　　Supports all Oracle Net protocols
　　Supports advanced connection options such as:
　　a. Connect-time failover
　　b. Source routing
　　c. Load balancing
　　SQL> CONNECT hr/hr@orcl

　　仅限共享模式：SGA->UGA
　　When Not to Use a Shared Server
　　Certain types of database work must not be performed using shared servers:
　　a. Database administration
　　b. Backup and recovery operations
　　c. Batch processing and bulk load operations
　　d. Data warehouse operations
　　Configuring CommunicationBetween Databases  配置交互在DB之间
　　Sending data or messages between sites requires network configuration on both sites.
　　You must configure the following:
　　Network connectivity (for example, TNSNAMES.ora)
　　Database links
　　CREATE DATABASE LINK

　　CONNECT TO >　　USING '';

　　例：
　　show  con_name;
　　alter  session  set  contaioner=pdb;
　　create  database link ......
　　connect to .....
　　using .......;
　　alter  pluggable database  pdb  open;
